| Specification | Description |
|---|---|
| Swing Over Bed: | 22.44" |
| Swing Over Saddle: | 14.57" |
| Recommended Machining Diameter: | 10" |
| Maximum Machining Diameter: | 15.75" |
| Maximum Work Length: | 25.6" |
| Draw Tube Diameter: | 3.03" |
| X - Axis Travel: | 11.10" (3.23" + 7.87") |
| Z - Axis Travel: | 26.77" |
| Cutting Feed Rates, X, Z: | 787, 944 IPM |
| Rapid Traverse Rate, X, Z: | 1968 IPM |
| Spindle Speeds: | 35 - 3500 RPM |
| Spindle Nose Taper: | A2-8 |
| Spindle Bore Diameter: | 3.54" |
| Number of Positions on Turret: | 10 |
| Tool Indexing Time: | .2 Seconds |
| Tailstock Quill Diameter: | 3.94" |
| Quill Bore Taper: | #5 MT |
| Quill Travel: | 3.94" |
| Machine Dimensions: | 170" x 66" x 72" High |
| Machine Weight, Approx.: | 12,500 Lbs. |
